PFW6648S

• Walk-thru frame and low step offer easy access and optimum visibility
• High back guard with movable walk-thru cross bar – relocate to fit your prime mover and application
• Standard forged clevis for lifting from a single point on the frame
• Certified, forged steel fork tines (ISO Class 2A) for strength and long life
• Robotically welded for consistent high quality

Frame Type
Walk-thru with full frame option

Coupler System Compatibility
Skid steer

Working Width (in)
48 (1,219 mm)

Approximate Operating Weight (lbs)
470

Fork Capacity at 19.7-inch From Tine Face (lbs)
6, 600

Fork Tine Dimensions ( L x W x H) (in)
48 x 3.9 x 1.8

Fork Tine Spread Range (in)
12-45 outside to outside

Fork Tine Type
Double hook lock down (ISO Class 2A)

Clevis
Standard
